ONKA 2.5 mm2 Connector for screw rail terminal block terminal for 2-wire blue DIN rail, 1010015

Online payment by card – after completing your order, you will be redirected to the payment page and receive a payment confirmation via email.

Cash on delivery – payment, according to the terms of sale, is made to the courier of the transport company.

Bank transfer – You will receive a proforma invoice by email no later than the next business day, containing the account number to use for payment.

On invoice with deferred payment – this payment method is available to partners who have signed a framework agreement with our company.

If you wish to use one of the latter two payment methods, please contact our account manager, who will provide you with instructions on how to receive an invoice with or without VAT.

The electrical devices we supply meet high quality standards, have a 24-month warranty, and comply with all EU requirements. In the event of a complaint, there are no costs for returning the goods.

Threaded connector for busbar / terminal for 2-wire DIN rail, blue, ONKA, made in Turkey

The ONKA coupler/terminal block is a reliable solution for those seeking functional and durable components in electrical installations.
Made with high-quality materials, the connector ensures prolonged use and resistance to mechanical damage.

Technical parameters

Single connected wire section up to: 2.5 mm2
Color: blue
Main housing insulating material: polyamide (PA6.6)
Contact/bridge material: CK45 steel/copper
Torque: 0.4 Nm
Connection position: side / side
Cable strip length: 10 mm
Type of electrical connection: screw terminal
Rated voltage: 750V
Rated current: 24A
Operating temperature from: -40°C
Operating temperature up to: 140°C
Mounting method: DIN 35 mm mounting rail
Standard: EN-60947-7-1
