ONKA 6mm2 spring connector for terminal block rail terminal block for 2-wire DIN rail gray, 1020034
- Regular price
- €1,24 €1,02 excl. VAT
- Regular price
-
- Sale price
- €1,24 €1,02 excl. VAT
- Unit price
- per
Couldn't load pickup availability
Notified by email when this product becomes available
Pre-order product
- Description
- Payment methods
- Warranty
Spring connector for busbar / terminal for 2-wire DIN rail, retractable contact, gray, ONKA, made in Turkey
ONKA compact installation rail couplers offer great possibilities to connect any wire of different cross-sections. The transparent housing allows easy checking of the correct wire arrangement. The original ONKA quick couplers represent installation convenience and 100% connection reliability.
Technical parameters
Single wire cross-section connected up to: 6 mm2
Color: gray
Main housing insulating material: polyamide (PA6.6)
Contact/bridge material: stainless steel/copper
Connection position: top / top
Cable strip length: 12 mm
Type of electrical connection: spring clamp / retractable contact
Rated voltage: 750V
Nominal current: 41A
Operating temperature from: -40°C
Operating temperature up to: 140°C
Mounting method: DIN 35 mm mounting rail
Standard: EN-60947-7-1
